Product Description:
One of the standout features of this portable glass drilling machine is its customized positioning accuracy. The CKD-EC1390-LDM120/ CKD-EC1390-LDM180 offers an accuracy of ±3μm + 5μm, ensuring that you can drill with extreme precision and achieve the desired results every time. This level of accuracy is essential for industries that require exact measurements and strict quality control.
Another impressive feature of this laser drilling machine is its repetition frequency. With a frequency range of 1-4000KHz, this machine can drill at high speeds with exceptional accuracy, making it ideal for industries that require high production output and efficiency.
The CKD-EC1390-LDM120/ CKD-EC1390-LDM180 also comes with a pulse width of 6-100ns, providing even more control over the drilling process. This allows you to choose the perfect pulse width for your specific material and application, ensuring that the drilling process is as efficient and effective as possible.
When it comes to cutting speed, this laser drilling machine can reach a maximum speed of 600mm/s, which is adjustable to suit your needs. This level of speed and flexibility is essential for industries that require fast and efficient drilling processes.
In summary, the CKD-EC1390-LDM120/ CKD-EC1390-LDM180 is an advanced and customizable laser drilling machine that offers unparalleled accuracy, speed, and efficiency. Whether you work in manufacturing, construction, or engineering, this automatic drilling machine laser is the perfect tool for achieving precise and consistent results every time. Invest in this portable glass drilling machine today and take your business to the next level!
Features:
- Product Name: Laser Drilling Machine
- Floor Load Capacity: >500Kg/m²
- Drilling Diameter: <100mm
- Model: CKD-EC1390-LDM120/ CKD-EC1390-LDM180
- Laser Wavelength: 1064nm
- Work Size: 1300*900mm
Keywords: glass drilling machine portable, yag laser drilling machine, glass hole drilling machine
Technical Parameters:
| Laser micro drilling machine |
|
| Laser drilling machine |
|
| Laser drilling machine |
|
| Cutting Thickness |
<20mm |
| Power Supply |
AC220V ±5%, L+N+E, <3KW |
| Cooling Method |
Water Cooling |
| Red Light Indication / Field of View |
Coaxial Red Light / Field Lens |
| Laser Wavelength |
1064nm |
| Cutting Speed |
0~600mm/s Adjustable |
| Chipping |
≤200μm |
| Equipment Dimensions |
Length 1900mm X Width 1800mm X Height 1900mm |
| Drilling Diameter |
<100mm |
| Positioning Accuracy |
±0.02mm |
Applications:
The CKD-EC1390-LDM120/CKD-EC1390-LDM180 automatic drilling machines laser are ideal for various applications. For instance, the machines are perfect for use in the production of glass hole drilling machine. They are designed to offer accurate and efficient drilling on different glass types. Additionally, the machines are ideal for use in the drilling of metal surfaces, including stainless steel, iron, and aluminum. The machines offer precise and clean drilling on the metal surfaces, allowing for the production of high-quality finished products.
The CKD-EC1390-LDM120/CKD-EC1390-LDM180 automatic drilling machines laser are also ideal for use in the production of yag laser drilling machine. The machines are equipped with MOPA Pulse Laser, which enables them to deliver high-quality drilling on different surfaces. Additionally, the machines have a cutting speed of 0~600mm/s adjustable, which makes them ideal for use in different drilling scenarios.
The CKD-EC1390-LDM120/CKD-EC1390-LDM180 automatic drilling machines laser come with pattern generation features that include EZcad + 2D Drawing / 2.5D Galvo Scanner. The machines have a work size of 1300*900mm and equipment dimensions of Length 1900mm X Width 1800mm X Height 1900mm. The machines are designed to deliver high-quality drilling while minimizing space usage.
